Engine Oil, Change
WARNING!
Hot oil and hot surfaces can cause burns.
Oil changes must be done when the engine is warm.
1 Connect the drain hose to the oil drain pump and
check that no leakage can occur.
2 Pump the oil out (or remove the bottom drain plug
and drain the oil).
Collect all
the old oil and old filters, and leave them
at a re-cycling station for destruction.
3 Remove the drain hose (or install the bottom drain
plug).
4 Fill with engine oil.
For change volume, please refer to Technical
Data page 82.
Oil Filter/By-pass Filter, Change
WARNING!
Hot oil and hot surfaces can cause burns.
1 Clean the oil filter bracket (2).
2 Remove all
oil filters with a suitable oil filter extrac-
tor (1).
3 Clean the mating surface of the oil filter bracket.
Make sure that no pieces of old oil seal are left
behind. Carefully clean round the inside of the pro-
tective rim (2) on the oil filter bracket.
4 Put a thin layer of engine oil on the seal rings of the
new fuel filters.
5 Install the new oil filters. Tighten the filters ¾–1 turn
after they touch.
6 Top up with engine oil, start the engine and let it run
for 20-30 seconds.
7 Turn off the engine, check the oil level and top up
as required.
8 Check sealing round the oil filters.
Maintenance
7748681 12-2011 63
