Type designation TAD1641VE TAD1642VE
TAD1643VE
TAD1650VE
Power, prime/stand-by Refer to the sales literature
Torque, Prime/Standby Refer to the sales literature
No. of cylinders 6 6 6
Bore mm (inch) 144 (5.67) 144 (5.67) 144 (5.67)
Stroke mm (inch) 165 (6.50) 165 (6.50) 165 (6.50)
Displacement liter (inch
3
)
16,12 (983.9) 16,12 (983.9) 16,12 (983.9)
Weight, dry kg (lb) 1480 (3263) 1480 (3263) 1425 (3142)
Weight, wet kg (lb) 1550 (3417) 1550 (3417) 1495 (3296)
Firing order 1-5-3-6-2-4 1-5-3-6-2-4 1-5-3-6-2-4
Compression ratio 17,5:1 17,5:1 18,0:1
Low idle, r/min. 600 600 700
High idle, rpm 1800 1800 1800–2000
Technical Data
7748681 12-2011 81
