15
ENGINE MOUNT INSTALLATION.
1) Locate the items necessary to install
the engine mount included with your
model.
2) Use four 4x30mm head bolts and four
4mm washers to attach the engine mount
rails to the ewall. Tighten the screws .
Make sure to use threadlock on the screws
to help prevent them from vibrating loose.
8) Use balsa block to hold in place the fuel
tank with C/A glue to secure the fuel tank
inside the fuselage
9) Connect the lines from the tank to the
engine and mu. vent line will con-
nectto the mu and the line from the
clunk tothe carburetor.
Fuel pick up tube. Fuel ll tube.
Ven tube.
