20
3) Attach the electric motor box to the
rewall suitable with the cross lines
drawn on the electric motor box and re-
wall. Using M4x25mm to secure the mo-
tor box to the rewall. Please see pictures
below.
4) Attach the motor to the front of the
electric motor box using four 4mm blind
nut, four M4x20mm hex head bolts to se-
cure the motor. Please see picture shown.
M4x25mm and washers.
en, use 5.5mm drill bit to enlarge the
holes on the electric motor box.
Blind nut.
You follow the same pattern on page 18
to drill hole mounted motor.
- Motor: 110 - 2000 Watts
- Propeller: 17x8 ~ 19x10
- ESC: 85A
- 8S- 9S Lipo
5.5mm
5mm
