INSTALLING THE BATTERY-RECEVER .
4) Epoxy canopy onto the fuselage. Trace
around the canopy and onto the fuselage
using a epoxy.
If you are going to install a pilot gure,
please use a sanding bar to sand the base
of the gure so that it is at.
3) Position the pilot gure on the canopy
oor as show. Locate the oval shaped on
the canopy oor and remove the cover-
ing. Use epoxy to glue this into the base of
the pilot gure and glue the cockpit panel
in place with C/A glue, please see pictures
as shown.
1) Plug the servos leads and the switch
lead into the receiver. Plug the battery
pack lead into the switch also.
2) Wrap the receiver and battery pack in
the protective foam rubber to protect
them from vibration.
Epoxy.
3) Route the antenna in the antenna tube
inside the fuselage and secure it to the
bottom of fuselage using a plastic tape.
Attach the aluminium tube into fuselage.
ATTACKMENT WING-FUSELAGE.
Epoxy.
