Seagull Models EDGE 540 - Aileron Control Horn Installation

www.seagullmodels.com
15
Secure the servos with the screws pro-
vided with your radio system.
Wing bottom.
Repeat the procedure for orther wing
haft.
Wing panel
bottom.
String.
Electric wire.
Pull.
AILERON CONTROL HORN INSTALLATION
2 sets.
3x40mm.

1) Aileron control horn:
Mix a small amount of 30 minute epoxy and
lightly coat the inside of the hole in the aileron
and the control horn screw.
Wing.
Aileron.
drill hole
3.2mm.
Wing bottom.
Plastic tape.
Aileron electric.
