Section 1: MECHANICAL INSTALLATION
1.6.4 Bonding Saddles to Hull
Note: This is a sample if using Plexus, if using another adhesive follow manufacturer’
recommendations.
If using Plexus MA590 adhesive, the Seakeeper saddles should be installed when PC-120
is confirmed dry.
1) Assemble Plexus cartridge into either the manual or pneumatic gun as shown. Remove cap
on cartridge and attach mixing tip. For pneumatic gun, start with low air pressure and
increase until desired flow rate is achieved.
2) Cut tip of mixing wand as shown in photo.
3) Prepare a second mixing wand as shown in photo below by attaching the simple flexible
nozzle to the end of the mixing tip. Set aside for now as this will be used to inject adhesive
into the sides of each saddle after the fixture / saddles are in position.
4) Install provided rubber plugs in six holes of each
saddle. The plugs will limit the adhesive being forced
out of the injection holes in step 6 below.
