Seakeeper 9 - Required Supplies Needed for Seakeeper Installation; List of Common Tools that May be Required for Installation

INSTALLATION
MANUAL
Product:
Document #:
Rev:
Page:
SEAKEEPER 9 / 7HD
90222
6
3 of 3
Section 5: INSTALLATION CHECKLIST AND SUPPLIES
5.1 Required Supplies needed for Seakeeper Installation
(not supplied with the Seakeeper)
Item
Description
Qty
Installation
Manual
Reference
Section
Other
Reference
System
1
Adhesive and cleaning supplies for bonding to hull
1
Mechanical
2
Soundproofing Considerations
1
Mechanical
3
Spreader bar for lifting the Seakeeper
1
Mechanical
4
Hose clamps for seawater plumbing to 3/4" (19 mm)
hose barb (2 per hose barb)
4
3
Cooling
5
M6 terminal lug for grounding Seakeeper at rear brace
1
2.3.1
Electrical
6
Cable, 10 AWG, for grounding Seakeeper at rear
brace to vessel ground (used with item 5)
AR
2.3.1
Dwg 90257
Electrical
7
Sea water pump, 230V AC
1
2.2.3
Electrical
8
Relay for sea water pump control
(Not required if using 230V AC pump)
1
2.2.3
Electrical
AR = As Required
Dwg = Drawing
List of common tools that may be required for installation
Item
Description
Use
1
Wire cutter
DC Power, AC Power cables
2
Wire stripper
DC Power, AC Power cables
3
3 mm hex key
Gimbal sensor mount plate
4
2.5 mm hex key
Gimbal angle sensor
5
1/4 inch nutdriver
Hose clamps
6
Terminal or quick disconnect crimper
Power cables
7
Utility knife
Scoring cable jackets
