INSTALLATION
MANUAL
Product:
Document #:
Rev:
Page:
SEAKEEPER 9 / 7HD
90222
6
1 of 3
Section 5: INSTALLATION CHECKLIST AND SUPPLIES
Please Complete Checklist and E-mail to customerservice@seakeeper.com
or telefax to +1.410.326.1199
5.0 Installation Checklist
Mechanical Checklist (reference Installation Manual Section 1)
 Seakeeper Foundation Installed in Hull
 Foundation bolts torqued to specification
Electrical Checklist (reference Seakeeper Drawing 90257 & Installation Manual Section 2)
Mount Components
 Display (near helm)
Connect Customer Supplied Cables
 Cable 1 (Seakeeper supplied) – Connect Cable 1 from Seakeeper 24VDC power
at customer supplied connection box, or
directly to a circuit breaker.
 – Plug connector of Cable 1 into mating
connector on the Seakeeper wire harness
 Cable 6 (customer supplied) – Install lugs on both ends of customer supplied
10 AWG ground cable
 – Connect one end of Cable 6 to nearest vessel
ground and other end to Seakeeper rear brace
Connect Seakeeper Supplied Cables
 Cable 2 (Seakeeper supplied) – Connect Cable 2 from Drive Box to 230 VAC
single phase at customer supplied connection
box or directly to circuit breaker
 Cable 5 (Seakeeper supplied) – Connect Cable 5 from Drive Box to customer
supplied 230 VAC seawater pump
