Section 1: MECHANICAL INSTALLATION
1.4 Unpacking Crate
1) Reference Seakeeper Drawing No. 90221, Seakeeper 9 Hardware Scope of Supply and
90415, Seakeeper 7HD Hardware Scope of Supply for items that ship with the
corresponding Seakeeper model.
2) Remove covers, electrical components, display, cables, and misc. items and set aside.
3) Remove packing materials that secure Seakeeper assembly inside the crate.
4) Attach spreader bar to the two lifting eyes located on the top of the Seakeeper
enclosure. Stay clear of any other parts on the Seakeeper. The Seakeeper 9 weighs
549 kg (1210 lbs). See Figure 4 below.
FIGURE 4 – LIFTING ARRANGEMENT
