Section 2: ELECTRICAL INSTALLATION
2.0 Introduction
This section for electrical installation explains how to mount the electrical equipment and how to
connect the electrical cables.
Reference Documents & Drawings
90221 Seakeeper 9 Hardware Scope of
Supply
90415 Seakeeper 7HD Hardware Scope of
Supply
90223 Seakeeper 9/7HD Operation Manual
90250 2
nd
Helm Control Station Kit
90257 Seakeeper 9/7HD Cable Block
Diagram (includes 2nd Display Kit)
90337 Color Operator Display Envelope
and Mounting Details
SEAKEEPER 9, Front Oblique View
24VDC Power Input Cable Terminator, Female Tee Adapter
Color Display Display Interface Cable 25m Cable
FIGURE 1 – ELECTRICAL EQUIPMENT FOR SEAKEEPER 9
CANvu 355 Display Interface Cable
20223
SEAKEEPER 9, Rear Oblique View
