Section 2: ELECTRICAL INSTALLATION
2.1 Electrical Equipment Mounting
Precautions
Each item of electrical equipment has specific mounting instructions. These instructions
should be followed to insure proper function of the Seakeeper.
1. COLOR DISPLAY MOUNTING INSTRUCTIONS, SURFACE MOUNT
a. Console space required: Approx. 4.57 W x 4.57 H inches (116 x 116 mm)
b. Mounting Instructions, Surface Mount: See drawing 90337 for details
2. SERIAL COMMUNICATIONS TEE ADAPTER AND TERMINATOR MOUNTING
INSTRUCTIONS
a. Console space required, Rear: Approx. 4 W x 3 H inches (102 x 76 mm), rear
b. Mounting Instructions: Rear mount on vessel console panel, within 1 ft (0.3m) of
Display.
c. Hardware required: One mounting screw for .197” (5 mm) diameter mounting
hole on Tee Adapter.
Do NOT move Seakeeper mounted components from their
locations or incorrect Seakeeper operation will result.
