SEAL 62C - On the Machine

10 User Manual 62C/62S
1.3.3 On the machine
On the machine (See Figure 1) you will find the following warning symbols in black on a
yellow background.
HOT OBJECTS (1)
DANGER OF GETTING BURN WOUNDS.
MAKE SURE NOT TO TOUCH THE UPPER MAIN ROLLER WHEN
HEATED.
This symbol is present only on the 62S and is placed on the inside side panel on both
sides of the machine, just above the upper main roller, visible from the front and rear side.
And on the image guide at the input side of the nip and on the output nip safety bar (1).
ROTATING PARTS (2)
DANGER OF GETTING INJURED BY ROTATING PARTS.
MAKE SURE THAT THESE ROTATING PARTS DO NOT CATCH YOUR
FINGERS, CLOTHING, HAIR, ETC.
This symbol is placed on in-feed table arms and on the cabinets just above the output
table (2).
ESD SHOCK (3)
DANGER OF GETTING AN ELECTRIC SHOCK CAUSED BY
ELECTROSTATIC CHARGE BUILD-UP IN THIS AREA.
This symbol is placed on those places where electrostatic charges can be build-up. The
machine parts close to the nip and the output material are most likely building up charges.
Therefore ESD-symbols are placed on the image guide and the output nip safety bars (3)
Figure 1: Warning symbol locations.
