Installation Instructions and Owner's Manual
PIN SIGNAL NAME DESCRIPTION
J1 BATT+ Power supply input (+) from 12V battery (red).
J2 BATT- Power supply input (-) from 12V battery (black or yellow).
J3 TRIM_UP Trim Up Output. Connected to engine power trim and tilt up
direction (blue).
J4 TRIM_DN Trim Down Output. Connected to engine power trim and tilt down
direction (green).
J5 PROTAP_SW ProTap Controller On/Off switch that acts as a wakeup line between
Normal and Smart modes.
J6 JPSW_UP ProTrim Jackplate Up switch input (blue).
J7 JPSW_DN ProTrim Jackplate Down switch input (green).
J8 SS0_GND SmartStick 0 ground line. If Jackplate Gauge is connected, this will not
need to be connected (black).
J9 SS0_POWER With Gauge Connected: Connect to the stud on the gauge labeled as "S".
Without a Guage Connected: Connect to the red wire of the SmartStick
on the port Jackplate.
J10 JP0_UP Connected to the port Jackplate up direction wire (blue).
J11 JP0_DN Connected to the port Jackplate down direction (green).
J12 SENDER_GND Digital trim sender input (-) from OEM device.
J13 SENDER_SIG Digital trim sender input (+) from OEM device.
J14 DIGITAL_IO1 Pending future software release.
J15 CAN0_H Isolated CAN High communication line from NMEA2K network (white).
J16 CAN0_L Isolated CAN Low communication line from NMEA2K network (blue).
J17 CAN0_POWER Isolated CAN power supply input (+) line from NMEA2K network (red).
J18 CAN0_GND Isolated CAN power supply input (-) line from NMEA2K network (black).
J19 DIGITAL_IO2
Connection for optional external 12V buzzer. Connect the pink lead of the
buzzer to this pin.
J20 TRIMSW_UP ProTrim, Trim Up switch input (blue).
J21 TRIMSW_DN ProTrim, Trim Down switch input (green).
J22 SS1_GND SmartStick 1 ground line (black).
J23 SS1_POWER SmartStick 1 position sense line (red)
.
J24 JP1_UP Connected to the starboard Jackplate up direction wire (blue).
J25 JP1_DN Connected to the starboard Jackplate down direction (green).
J26 ANALOG_GAUGE Third party analog gauge output (+). 0-5V output based on SmartStick
0 position.
J27 ANALOG_GND Third party analog gauge output (-).
J28 DIGITAL_IO0 Digital input to enter calibration mode and recalibrate system. Connect
12V to this line at power on to enter calibration mode.
Table 4-1.
