14
SeaStar ProTap Controller
KIT NO. DESCRIPTION APPLICATION
PTK5010 Harness, ProTap, CAN, NMEA 2000 All engines with NMEA
network gateway
PTK5020 Harness, ProTap, for Yamaha 2 wire senders Yamaha V6 and smaller
PTK5021 Harness, ProTap, for Yamaha 3 wire senders Yamaha V8
PTK5040* Harness, ProTap, for Mercury Optimax/ProXs with SmartCraft Mercury ProXs, Optimax with
SmartCraft network
PTK5041 Harness, ProTap, for Mercury Verado sender Mercury Verado
* This part number is a for a digital trim sender that is specific to the Mercury SmartCraft network.
Table 4-2. Trim signal wiring harnesses.
Direct Trim Signal
Wiring Harnesses
Pro Trim Switch
Input
Jackplate SmartStick
Gauge (not supplied)
External Buzzer
(not supplied)
Twin engines can not use a direct connection and
MUST use NMEA 2000 harness PTK5010.
Please refer to PT1000/PT2000 PT1000-1/PT2000-1
single/dual bezel installation instruction supplied with
Pro Trim switch for installation details.
Please refer to System Diagrams in Section 3.2 for
gauge installation.
ProTap can operate with a SeaStar Jackplate Gauge
DW0148. This is sold separately from the ProTap controller.
Please refer to System Diagrams in Section 3.2 for
optional buzzer installation.
The ProTap controller has an internal buzzer that, along
with the diagnostic LED, notify the operator as to the
system status. In addition to the internal buzzer, an
external 12V buzzer may be installed should the operator
require a more audible feedback from the ProTap system.
An external buzzer is required if the ProTap controller is
mounted in an area where the internal buzzer cannot be
heard or is difficult to hear while the boat is underway.
WARNING
