Seastar Solutions Seastar PROTAP Controller User Manual

15
Installation Instructions and Owner's Manual
TRIM SENDER T-HARNESS
Figure 4-3. Trim Sender connection.
Direct Trim Sender
Connection
If you are connecting an analog trim sender harness it
is important to locate a proper trim sender connector.
Trace the wire from the trim sender in the midsection
all the way to the connector. Once the trim sender
T-harness is connected run the wire to the controller
through the engine rigging tube.
