Security Tronix ST-HDoC User Manual

ST-HDoC / ST-HDoC-MM
35
PTZ Controller
Communication
RS485 / UTC
PTZ Protocol
Compatible with more than 30 protocols such as PELCO-D/P, Samsung,
Panasonic, Lilin, Yaan, etc.
Baud Rate
600,1200, 2400, 4800, 9600, 19200, 57600, 115200bps
Video Signal Generation
Color bar generator
Supports both PAL / NTSC format’s standard color bar output (Red, Green,
Blue, White, Black, Grey)
UTP Cable Tester
UTP cable test
Displays UTP cable connection status , cable type and sequence of wires
12V DC (1A) Power Output
12VDC power output
12V DC (1A) Output for powering cameras
Audio Input Test
Audio input test
1 channel audio signal input, support audio recording
RS485 data analysis
Data Monitor
Captures and analyzes the command data from a controlling device
CVI Test
CVI video signal test
1 channel CVI input（BNC interface）, supports 720p 25 / 30 / 50 / 60fps,
1080p 25 / 30fps, coxial PTZ controller, UTC control
TVI Test
TVI video signal test
1 channel TVI input（BNC interface）, supports 720p 25 / 30 / 50 / 60fps,
1080p 25 / 30fps, coxial PTZ controller, UTC control
AHD Test
AHD video signal test
1 channel AHD input (BNC interface）, supports AHD 2.0, 720p 25 / 30fps,
1080p 25 / 30fps, coxial PTZ controller, UTC control
SDI Test（ST-HDoC-MM)
SDI video signal test
1 channel SDI input (BNC interface）, support 720p 50 / 60fps, 1080p 50 /
60fps, PTZ controller
