Security Tronix ST-HDoC User Manual

ST-HDoC / ST-HDoC-MM
36
Digital Multimeter ( ST-HDoC-MM)
AC/DC Voltage
0-660V auto/manual range, minimum resolution of 0.1mV
AC/DC current
660.0uA , 6.600mA, 66.00mA , 660.0mA, 10.00A
Resistance
660.0Ω, 6.600kΩ, 66.00kΩ, 660.0kΩ, 6.600MΩ, 66.00MΩ
Capacitance
6.6nf～66000uF, minimum resolution of 1pf
Diode
0～2V forward voltage, minimum resolution of 1mV
Data hold
Hold and display the measured value
Relative measurement
Display the relative power value
Continuity testing
Built-in buzzer will sound, if resistance is lower than 50 Ω
Testing speed
3 samples per second
Data range
-6600～+6600
POWER
Power Adapter
5V DC（1.5A）Mini USB interface
Battery
Built-in 3.7V Lithium polymer battery ,3000mAh
Rechargeable
After charging 3-4 hour, 11 hour average work time
Low Consumption
Energy saving , battery capacity indicator
Parameter
Operation setting
OSD menu, select your desired language: English, Chinese, etc
Auto off
5-60 (mins)
Keytone
On/Off
General
Working Temperature
14°F～122°F
Working Humidity
30%～ 90% relative humidity
Dimension/Weight
7.6” x 4.4” x 1.8” / 1.1lbs.

Security Tronix ST-HDoC Specifications

General

Brand	Security Tronix
Model	ST-HDoC
Category	Measuring Instruments
Language	English
