7. Specifications
Model
DVR4CHSOUH264
No. of cameras 4
Split display mode 1, 4
Operation Mouse / IR remote control
Multiplex mode Quadruplex (Live/Record/Playback/Ethernet)
Display resolution (VGA) 1280x1024
Live frame rate 120fps (NTSC), 100fps (PAL)
Colour 16M colours (Y:8, U:8, V:8) 4:2:2
Playback mark Yes
Watch dog Yes
Function
Wall mount Yes
NTSC: 640x480, PAL: 640x512
Resolution
(1280x1024 at quad mode)
Frame rate 60fps (NTSC), 50fps (PAL)
Recording quality 5 levels
Compression algorithm H.264 enhanced
Max. compression rate 300:1
Motion recording Yes
Pre-recording 3 sec ~ 10 sec
Record
Post-recording 1 sec ~ 255 sec (programmable)
Search mode Smart search by file/event/frame/time/date
Search speed Date, hour, min, sec, frame, pause
Playback
Playback speed Pause, x1, x5, x15, x60
Video out VGA x1
Audio line in RCAx2 (1 Vp-p)
Audio line out RCA (L,R) (1 Vp-p)
Ethernet 10/100M RJ45x1
DC jack x1 (12V)
DSUB9
1 (Alarm-in x4, Alarm-out x1)，relay
IR extension jack x1
IR extension cord option
IR receiver Yes
Connector
USB port x2 (Mouse x 1/ USB flash x 1)
Motion detection 12 (4x3) motion zones
Alarm/Motion
