CT Type

Select the connected CT Type (for the display of primary or relative phase current values).

Selection list referenced by the following parameters:

•

╚═▷ CT . CT Type

•

• ╚═▷ CT . CT Type•

CT Type Description

Relative Phase current values are displayed as relative values.

WE2 : 16 A ... 56 A Phase current values are displayed as primary values, that are calculated based on the

connected CT type with primary current range 16 A ... 56 A.

W2 : 16 A ... 56 A Phase current values are displayed as primary values, that are calculated based on the

connected CT type with primary current range 16 A ... 56 A.

W3 : 32 A ... 112 A Phase current values are displayed as primary values, that are calculated based on the

connected CT type with primary current range 32 A ... 112 A.

W4 : 64 A ... 224 A Phase current values are displayed as primary values, that are calculated based on the

connected CT type with primary current range 64 A ... 224 A.

W5 : 128 A ... 448 A Phase current values are displayed as primary values, that are calculated based on the

connected CT type with primary current range 128 A ... 448 A.

W6 : 256 A ... 896 A Phase current values are displayed as primary values, that are calculated based on the

connected CT type with primary current range 256 A ... 896 A.

Standard Standard

Polarity

Selection list referenced by the following parameters:

• ╚═▷ CT . CT Shift by 0°/180°•

•

╚═▷ CT . ECT Shift by 0°/180°

•

Polarity Description

0 0

180 180 degree polarity correction (wiring faults)

Meth.Detect.Bkr.Pos.

Select the method to be used to determine the connected breaker position.

Selection list referenced by the following parameters:

• ╚═▷ Prot . Meth.Detect.Bkr.Pos.•

138 WIC1 WIC1-2.0-EN-REF

13 Selection Lists
