Seg WIC1 Reference Manual

I>>> . IH2 Blo [Protection Para / I>>>]
Active If: IH2 . Mode = use
• Inactive, Active•
If: IH2 . Mode = “-”
• Inactive•
╚═▷ Mode
P.1
Blocking the trip command, if an inrush is detected.
I>>> . Stab. by CLPU [Protection Para / I>>>]
Inactive
Only available if:
• CLPU . Mode = use•
Inactive, Active
╚═▷ Mode
P.1
Select whether the CLPU stabilization shall be e󰅯ective for this protection stage. (If set to “active” then further
settings are available within the CLPU menu.)
I>>> . ExBlo [Protection Para / I>>>]
“-” “-” . . . Prot . Pos OFF
╚═▷
P.1
External blocking of the module if the state of the assigned signal is true.
9.10.3
I>>>: Input States
I>>> . ExBlo-I [Operation / Status Display / I>>>]
Module input state: External blocking
9.10.4
I>>>: Signals (Output States)
I>>> . Active [Operation / Status Display / All Actives]
[Operation / Status Display / I>>>]
Signal: active
I>>> . Trip [Operation / Status Display / Trips]
[Operation / Status Display / I>>>]
Only available if:
• I>>> . De󰊟nition = Trip•
Signal: Trip
68 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.10.3 I>>>: Input States
