20
CARD READER/WRITER
7
4
Insert a new cleaning card. Place the retainer on top of the cleaning card.
7-2 FIG. 06
7-2 FIG. 07
CLEANING CARD
5
Select CLEAN STOCKER and press the test button. Roller cleaning will commence. During cleaning “CLEAN-
ING STOCKER ROLLER” will display in the UNIT STATUS area, and change to “DONE” when complete.
7-2 FIG. 08
IC CARD R/W & PRINTER TEST
RESET UNIT
CHECK CARD
CHECK PRINTER
CHECK STOCKER
CLEAN ROLLER
->CLEAN STOCKER
ERASE PRINT
EXIT
UNIT STATUS : CLEANING STOCKER ROLLER
UNIT RESULT : ---
SENSOR(PT1) :OFF
SENSOR(PT3) :OFF
SENSOR(PT4) :OFF
SENSOR(PT5) :OFF
SENSOR(PT6) :OFF
SENSOR(DISPENSER) :OFF
SENSOR(SHUTTER1) :OFF
SENSOR(SHUTTER2) :OFF
SELECT WITH SERVICE BUTTON
AND
PRESS TEST BUTTON
(Display during cleaning)
NOTE: Display changes to
“DONE” when complete.
