Seiko MTP Series User Manual

2.2 GENERAL SPECIFICATIONS
2.2.1 Character Printers
Table 2-1 Character Printer Specifications
Item Specifications
Base model code MTP102 MTP201 MTP401
Model MTP102-13B MTP102-16B MTP201-20B MTP201-24B MTP401-40B
Printing method Thermal serial dot printing
Printing direction Left to right with respect to the direction the paper is fed.
Dots per line
(H×W / line)
7 dots × 89 dots 7 dots × 110 dots 7 dots × 138 dots 7 dots × 166 dots 7 dots × 278 dots
Paper feed pitch
(H×W)
0.35mm × 0.30mm 0.35mm × 0.24mm 0.35mm × 0.33mm 0.35mm × .28mm 0.35mm × .24mm
Character matrix
(H×W)
7 × 5 dot matrix
Character size
(H×W)
2.4mm × 1.5mm 2.4mm × 1.2mm 2.4mm × 1.6mm 2.4mm × 1.4mm 2.4mm × 1.2mm
Characters per line
13 dot
(2 dot spaces)
16 dot
(2 dot spaces)
20 dot
(2 dot spaces)
24 dot
(2 dot spaces)
40 dot
(2 dot spaces)
Printing width 26.7mm 26.4mm 45.9mm 46.0mm 66.7mm
Printing speed
(room temperature,
5.0V)
Approx. 1.5 line / s Approx. 1.2 lines / s Approx. 1.0 line / s Approx. 0.9 line / s Approx. 0.5 line / s
Paper feed pitch 3.8mm
Head activation
timing detection
Via a tachogenerator
Home position
detection
Via a mechanical switch
Operating voltage
range
DC5.0V ± 1.0V
2-2
