Seiko MTP Series User Manual

2.2.2 Graphic Printers
Table 2-2 Graphic Printer Specifications
Item Specifications
Base model code MTP201 MTP401
Model MTP201-G128 MTP201-G166 MTP401-G280
Printing method Thermal serial dot printing
Printing direction Left to right with respet to the direction the paper is fed.
Dots per line
(H×W / line)
8 dots × 128 dots 8 dots × 166 dots 8 dots × 280 dots
Paper feed pitch
(H×W)
0.35mm × 0.35mm 0.35mm × 0.28mm 0.35mm × 0.24mm
Character matrix
(H×W)
7 × 5 dot matrix
Character size
(H×W)
2.4mm × 1.7mm 2.4mm × 1.4mm 2.4mm × 1.2mm
Character per line
18 dot
(2 dot spaces)
24 dot
(2 dot spaces)
40 dot
(2 dot spaces)
Printing width 44.7mm 46.0mm 67.2mm
Printing speed (room temperature, 5.0V) Approx. 0.9 line / s Approx. 0.9 line / s Approx. 0.5 line / s
Paper feed pitch 2.8mm
Head activation timing detection Via a tachogenerator
Home position detection Via a mechanical switch
Operating voltage range DC5.0V ± 1.0V
2-4
