* Signal in are issued from the circuit side.
One cycle
Motor drive signal
Paper feeding
Printing
Motor current
Motor stop signal
Home switch signal
Starting of timing signal detection
TG signal
Timing signal
Starting of first character printing
Dot 1
Dot 2
Dot 3
Head drive
signal
Dot 4
Dot 5
Dot 6
Dot 7
2-dot space between characters
Print
Figure 4-1 Timing Chart
