14. SETTINGS WHEN USING 58mm PAPER WIDTH
Ensure that the printer is off. (1)
Operate the release lever to open the paper cover. (2)
Put the attached partition plate L and partition plate R into the paper holder with slanting position as (3)
shown in Figure 14-1.
Partition plate L Partition plate R
Tension roller
Figure 14-1 Partition Plate Installation (1)
Rotate the partition plate L and partition plate R within the paper holder in the direction of the arrow (4)
shown in Figure 14-2 to make the side surface of the paper holder and the partition plate in parallel.
Figure 14-2 Partition Plate Installation (2)
