U.3.2
SEL-421/SEL-421-1 Relay User’s Guide Date Code 20020501
PC Software
Installing the Computer Software
Installing the Computer Software
Load the ACSELERATOR software on an IBM-compatible PC. If you
encounter any difficulties installing the
ACSELERATOR software, contact your
Technical Service Center or the SEL factory for assistance. See Factory
Assistance on page U.6.43 in the User’s Guide for contact information.
System
Requirements
To successfully install and use the ACSELERATOR software, your computer
must have the minimum resources listed in Table 3.1.
Installation
You can load the ACSELERATOR software automatically if your computer
autorun feature is enabled; this is Method A. If autorun is not enabled on your
computer, use the Windows Run command to load the
ACSELERATOR
software; this is Method B.
Perform the following steps to install the
ACSELERATOR software:
Step 1. Load the
ACSELERATOR software using one of the following
methods:
➢ Method A. Load the ACSELERATOR software
automatically. To load the software automatically, turn
on your PC and run the Windows operating
environment. Close all other applications on your PC.
Place the
ACSELERATOR CD-ROM in the PC CD-
ROM drive. The setup software should run
automatically and the SEL Software License
Agreement will appear as in Figure 3.1.
Table 3.1 System Requirements for ACSELERATOR Software
Item Description
Processor Pentium
®
class, ³ 90 MHz
Operating System / RAM Microsoft
®
Windows
®
95/98/ME–64 MB RAM
Microsoft Windows 2000–64 MB RAM
Microsoft Windows NT
®
–32 MB RAM (64 MB recom-
mended)
Hard drive At least 25 MB available storage space
Communications Port One EIA-232 serial port or one Ethernet port (SEL-2701
Ethernet Processor installed in the relay)
Drives CD-ROM for software installation
Monitor SVGA 800 x 600 pixel resolution or greater (1024 x 768
pixel resolution recommended)
Pointing Device Mouse or other pointing device
