U.4.51
Date Code 20020501 User’s Guide SEL-421/SEL-421-1 Relay
Basic Relay Operations
Reading Oscillograms, Event Reports, and SER
=>FILE DIR REPORTS <ENTER>
BRE_1.TXT R
BRE_2.TXT R
BRE_S1.TXT R
BRE_S2.TXT R
CBRE.TXT R
CHISTORY.TXT R
CSER.TXT R
HISTORY.TXT R
SER.TXT R
=>
Figure 4.46 Reports File Structure.
Step 4. Download the SER report. Perform the steps necessary for your
terminal emulation program to receive a file. Typically, these
are the file transfer steps:
➢ Specify the destination file location in your computer
file storage system and file name.
➢ Select the transfer type as Y-Modem (if not already
enabled).
➢ Click on Receive.
You will usually see a confirmation message when the file
transfer is complete.
Step 5. Confirm a successful download. When the SER.TXT file has
transferred successfully, use a word-processing program to
view the contents of the file. You will see the SER records in a
format similar to Figure 4.44. The CSER.TXT file viewed with
a word-processing program is similar to the example in CSER,
SER (Sequential Events Recorder), in CSER on page A.3.35 in
the Applications Handbook.
