After selecting the operating modes and setting up the operating limits, it is necessary to determine the operating point of
the regulation: the SET-POINT, on the basis of the scales and ranges referring to the connected sensor (*).
The Set-Point is easily and quickly fixed through the couple of 13-position rotary switches, named as follows: SP
(main reference point for the regulation) and SPadj. (accurate adjustment of the operating point fixed with SP).
For the selection of the Set-Point values, refer to the following tables according to the ranges and to the types of sensors
in use.
(*) The controller ESY-1 operates automatically according to the sensor/signal currently connected or in use.
9.5. Tables for the Set-Point selection:
Set
Point
=
The Set-Point value is the
result of
SP +/- SP adj.
9.5.1. Set-Point values, range 4-20 mA (Transducer 4-20 mA)
4-20mA
-6 -5 -4 -3 -2 -1 +1 +2 +3 +4 +5 +6
7,00 7,05 7,15 7,25 7,35 7,45
1
7,56 7,66 7,76 7,86 7,96 8,06 8,11
7,51
7,56 7,66 7,76 7,86 7,96 2 8,06 8,16 8,26 8,36 8,46 8,56
8,61
8,51
8,56 8,66 8,76 8,86 8,96 3 9,06 9,16 9,26 9,36 9,46 9,56
9,61
9,51
9,56 9,66 9,76 9,86 9,96 4 10,06 10,16 10,26 10,36 10,46 10,56
10,61
10,51
10,56 10,67 10,77 10,87 10,97 5 11,07 11,17 11,27 11,37 11,47 11,57
11,62
11,52
11,57 11,67 11,77 11,87 11,97 6 12,07 12,17 12,27 12,37 12,47 12,57
12,62
12,52
12,57 12,67 12,77 12,87 12,97 7 13,07 13,17 13,27 13,37 13,47 13,57
13,62
13,52
13,57 13,67 13,78 13,88 13,98 8 14,08 14,18 14,28 14,38 14,48 14,58
14,63
14,53
14,58 14,68 14,78 14,88 14,98 9 15,08 15,18 15,28 15,38 15,48 15,58
15,63
15,53
15,58 15,68 15,78 15,88 15,98 10 16,08 16,18 16,28 16,38 16,48 16,58
16,63
16,53
16,58 16,68 16,78 16,88 16,99 11 17,09 17,19 17,29 17,39 17,49 17,59
17,64
17,54
17,59 17,69 17,79 17,89 17,99 12 18,09 18,19 18,29 18,39 18,49 18,59
18,64
18,04 18,09 18,19 18,29 18,39 18,49
13
18,59 18,69 18,79 18,89 18,99 19,09 19,14
9.5.2. Set-Point values, range 0-15 bar (Transducer 4-20 mA)
0-15 bar
-6 -5 -4 -3 -2 -1 +1 +2 +3 +4 +5 +6
2,82 2,86 2,96 3,05 3,14 3,24
1
3,33 3,43 3,52 3,62 3,71 3,80 3,85
3,29
3,33 3,43 3,52 3,62 3,71 2 3,80 3,90 3,99 4,09 4,18 4,27
4,32
4,23
4,27 4,37 4,46 4,56 4,65 3 4,74 4,84 4,93 5,03 5,12 5,21
5,26
5,17
5,21 5,31 5,40 5,50 5,59 4 5,68 5,78 5,87 5,97 6,06 6,15
6,20
6,11
6,15 6,25 6,34 6,44 6,53 5 6,62 6,72 6,81 6,91 7,00 7,09
7,14
7,05
7,09 7,19 7,28 7,38 7,47 6 7,57 7,66 7,75 7,85 7,94 8,04
8,08
7,99
8,04 8,13 8,22 8,32 8,41 7 8,51 8,60 8,69 8,79 8,88 8,98
9,02
8,93
8,98 9,07 9,16 9,26 9,35 8 9,45 9,54 9,63 9,73 9,82 9,92
9,96
9,87
9,92 10,01 10,10 10,20 10,29 9 10,39 10,48 10,57 10,67 10,76 10,86
10,90
10,81
10,86 10,95 11,05 11,14 11,23 10 11,33 11,42 11,52 11,61 11,70 11,80
11,84
11,75
11,80 11,89 11,99 12,08 12,17 11 12,27 12,36 12,46 12,55 12,64 12,74
12,79
