OUTPUT SIGNALS
Config. 0M
V1
Transducer voltage supply 22V (+10/-20%) max. 25mA
V2
Transducer voltage supply 22V (+10/-20%) max. 25mA
+ 10V
Transducer voltage supply 10,0V (±1%)
OUT
Output signal for slave unit: 0-10Vdc or PWM (MAX 5 modules)
Config. 0X
V1
Transducer voltage supply 22V (+10/-20%) max. 25mA
V2
Transducer voltage supply 22V (+10/-20%) max. 25mA
+ 10V
Transducer voltage supply 10,0V (±1%)
OUT
Output signal for slave unit: 0-10Vdc or PWM (MAX 5 modules)
Config. 0V
V1
Transducer voltage supply 5,0V (±1%)
V2
Transducer voltage supply 5,0V (±1%)
+ 10V
Transducer voltage supply 10,0V (±1%)
OUT
Output signal for slave unit: 0-10Vdc or PWM (MAX 5 modules)
Config.0B
V1
Transducer voltage supply 22V (+10/-20%) max. 25mA
V2
Transducer voltage supply 5,0V (±1%)
+ 10V
Transducer voltage supply 10,0V (±1%)
OUT
Output signal for slave unit: 0-10Vdc or PWM (MAX 5 modules)
Config.SV
+ 10V
Transducer voltage supply
OUT
Output signal for slave unit: PWM (MAX 5 modules)
PROTECTIONS
EMC mains filter Compliance 89/336
Conformity for devices that are directly connected to the low voltage mains
Overvoltage Protection Complying with EN 61000-4-5 : overvoltage category II (4 KV)
Control Input Protection Protection from electrical disturbances of the connection
Transducer Supply Protection Protection from short circuit of the transducer output supply
CASE
Materials GW-Plast 120°C (max. temperature 120°C) aluminium, fiberglass
Protection degree
IP 55 (standard)
IP 00 (on request)
MAX Heatsink Temperature 60°C
Environmental Pollution Low Pollution
Fire Resistance D Category
INSULATION
Endurance of the insulation materials
against electrical stress
Long
Control Circuits
Class
I
(use of protective earthing conductor)
2000 Vac
between grounding and voltage supplied components of the device
2500Vac
between control input and voltage supplied components of the device
4000 Vac
between control input and mains supplied components
WORK
ENVIRONMENT
Working Temperature
-
20 T 50
( from –20°C to + 50°C )
Storage Temperature
-
30 T 85
( from –30°C to + 85°C )
Vibrations Lower than 1G (9.8 m/s
2
)
Ageing Characteristics 60.000 hours
INSTALLATION
Wall mounting ONLY in vertical position, with N° 4 holes
5 mm, providing at least 10 mm insulation around the device
The device is suitable for the installation in class I, II, III equipments .
