SemaConnect Single/Dual Pedestal Installation Procedure
• Once the concrete has set, remove the Sacrificial bolts from the anchor plate.
• Then place the pedestal on top of anchor plate and screw in four pedestal mounting screw. Do not
tighten it fully.
• Make sure the electrical wire is passed through the pedestal.
• Ensure that access panel is to your right, when seen from the front end.
• Align Pedestal for plumb with the help of Set screw on the pedestal. Once the Pedestal is plumb, fully
tighten the pedestal mounting screw.
Installation Manuals Series 6 EV Charging Station - 1
Copyright ©2021 SemaConnect, Inc. All rights reserved. Page 16 of 25
