SMD 989– User Manual
Page 96 (105)
AC Power –
Operating Voltage: 95-135 VAC or 180-265 VAC
Current Draw/Power: 200 Watts
Frequency: 47-63Hz
Line Cord: Detachable, 3-prong
General –
RoHS Compliant: Yes
Operating Temperature: 0 to 45 degrees C
Operating Humidity: <95% Non-Condensing
Cooling: Forced air, front intake, rear exhaust
Temperature monitor: Fan failure, internal temperature sensor
Size: Height = 1RU (13/4”), Width = 19”, Depth = 19”
19 in. rack mountable, removable ears
Rack clips and screws included
Weight: ~9.5 lbs. (base unit)
~12.75 lbs. (Fully Loaded)
Pollution Degree: 2
Installation Category: II
Grounding Post: On chassis
Grounding Thread Size: 8/32”
SMD 952 Dual Redundant AC Power Supply – Option
Operating Voltage: 95-135 VAC or 180-265 VAC
Current Draw: 275 Watts
Frequency: 47-63Hz
Line Cord: Detachable, 3-prong
Redundancy Dual Hot Swappable Load Sharing
SMD 954 Dual Redundant DC Power Supply – Option
Operating Voltage: -40 to -72VDC, Normal -48VDC
Current Draw: 250 Watts
Frequency: 0Hz
Connection: Screw Terminal, -48VDC and 0VDC
Redundancy Dual Hot Swappable Load Sharing
SMD 910 Single Stream Modulator
General –
RoHS Compliant: Yes
ASI Serial TS Input –
Connector: (4) BNC, female
Impedance: 75 ohms
Standard: ETSI EN 50083-9 DVB ASI
Data Bit Rate: 270 Mbps
Packet Size: 188 or 204 byte support
Transmission Mode: Burst and packet mode support
Min TS Rate Supported: 0.5 Mbps
Max TS Rate Supported: 160 Mbps
Specifications are subject to change without notice.
