When is it necessary to calibrate the pumps?
When the pump tube is changed.
2QO\FDOLEUDWHWKHSXPSRIZKLFK
the tube has been changed)
When the electronic card is changed
(Calibrate both pumps)
When the pump/pump motor is
changed.
(Calibrate only the new pump)
2
6
7
5
8
D i s c o n n e c t
suction tube
Separate the suction
tube from the suction
valve support accord-
ing to the pump to be
calibrated.
/RZHU WKH FRQWURO
lever
When
MIR???
appears
on the screen, lower the
left control lever if the left
pump is to be calibrated
or lower the right control
lever if the right pump is to
be calibrated or both.
Select calibration
Press button
.
Press button .
C o m m e n c e
calibration
:DLWIRUFDOLEUDWLRQWRȴQLVK
When pump calibration
KDVȴQLVKHGTest Ok or
Ok New Set PP will
appear on the screen.
Press button
.
3 4
Select the Pump to calibrate
(QWHUWKH/RDGLQJ&OHDQLQJ&DOLEUDWLQJPHQX
2QWKHPHQXXVHWKH
to select the cylinder of the
pump to be calibrated.
Press button .
1
Empty machine
)ROORZ WKH VWHSV
from the “Emptying”
FKDSWHU3J
