Sencotel 153 - Dismantling

:LWKGUDZERG\RIWDS
Remove spiral Paddle
Dismantle the body of the tap
Dismantle spiral Paddle
/RRVHQVORZO\DQGZLWKGUDZWKHIRXUNQREVWDNH
out the tap body by pulling towards the outside of
the machine.
Extract the spiral paddles from their housing in the
cylinder but take care not to hit the walls of the cyl-
inder.
- Using the control levers (A) raise the pistons (X)
and (Y).
([WUDFWWKHMRLQW&DQGWKHȴOWHURIWKHWDS'
- Extract the control levers A.
- Extract the pistons (X) and (Y) from their position.
- Extract the bolts from the body of the tap (E).
- Extract the rest of the washers.
Remove the gasket and the spiral by sliding them
along the axis.
1.1
2.1
1.2
2.2
A
C
E
E
D
X
Y
21
6.Cleaning
6.2 Cleaning and hygiene
6.2.2 Dismantling
Dismantling
'LVPDQWOLQJWKH7DS
'LVPDQWOHWKHVSLUDO3DGGOH
