Putting the receiver into operation
19
Connecting the mains unit
Only use the supplied NT 2-3 mains unit. It is designed for your receiver
and ensures safe operation.
To connect the NT 2-3 mains unit:
왘 Connect the yellow connector of the mains unit to the yellow
socket at the rear of the receiver.
왘 Pass the cable of the mains unit through the cable grip .
왘 Slide the supplied country adapter onto the mains unit .
왘 Plug the mains unit into a wall socket.
The STANDBY button is backlit in red.
542.625
SKM500
ew500 G3
B.Ch: 20.30
PEAK
EQ
+ 12dB
P
-10
0
40
30
20
10
-20
-30
-40
AF
RF
MHz
P
