Putting the receiver into operation
17
To mount the antennas:
왘 Use remote antennas, if necessary in conjunction with the ASA 1
antenna splitter (see “Accessories and spare parts” on page 53).
To mount the receivers into the rack:
왘 Slide the receivers into the 19” rack.
왘 Secure the rack mount “ears” to the 19” rack.
Connecting an amplifier/mixing console
The receiver’s ¼” (6.3 mm) jack socket and XLR-3M socket are
connected in parallel, allowing you to simultaneously connect two devices
(e.g. amplifier, mixing console) to the receiver.
왘 Use a suitable cable to connect the amplifier/mixing console to the
¼” (6.3 mm) jack socket or the XLR-3M socket .
For detailed information on balanced and unbalanced connection,
please refer to the chapter “Connector assignment” on page 57.
XXX - XXX MHzFREQ. RANGE-X:
SER. NO.: XXXXXXXXXX
TRUE DIVERSITY RECEIVER EM 5 00
IDENT. NO.: XXXXXX
IC: 2099A-XXXXXXX
DESIGNED IN GERMANY, ASSEMBLED IN USA
0682
