SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 7008
May 25/11
23-41-48
F. Installation of the optical waveguide
NOTE:
THIS PROCEDURE IS ONLY APPLICABLE TO THE HMEC 26-T HEADSET.
NOTE:
REFER TO IPL FIG. 3 AND IPL FIG. 4.
(1) Carefully push the optical waveguide (030, Fig. 4; 046, Fig. 3) into the the cap (040, 070)
from outside the cap (040, 070).
G. Installation of the clip
NOTE:
FOR HMEC 26, REFER TO IPL FIG. 1 AND IPLFIG. 2.
FOR HMEC 26-T, REFER TO IPL FIG. 3 AND IPL FIG. 4.
(1) Put the clip (030, Fig. 3; 010, Fig. 2) in position on the cap (040, Fig. 1, Fig. 3; 070, Fig. 1,
Fig. 3) and move it down to fix it (see the black arrow).
H. Installation of the Talk Through rocker button
NOTE:
THIS PROCEDURE IS ONLY APPLICABLE TO THE NON MICROPHONE SIDE CAP OF THE HMEC 26-T
HEADSET.
NOTE:
REFER TO IPL FIG. 3.
(1) Carefully push the Talk Through rocker button (045) into the cap (040) from outside.
I. Installation of the Cable
NOTE:
THIS PROCEDURE IS NOT APPLICABLE TO HEADSETS WITHOUT A CABLE.
NOTE:
FOR HMEC 26, REFER TO IPL FIG. 1 AND FOR HMEC 26-T, REFER TO IPL FIG. 3.
FOR THE HEADSETS, REFER TO IPL FIG. 17.
(1) Plug the Cable (110) into the system connector of the headphone cap on the
microphone side (070).
(2) Fasten the screws (010) to the system connector at the headphone cap on the
microphone side (070) with a torque of 25 Ncm +5 Ncm.
Oct 30/08
