Product overview
Set 880 | 7
Overview of the transmitter
Model: TR 880
6
7
4
1
2
3
12345
1A
5
12345
0
A
9
2
8
1 Battery LED ,
indicating the charging process/
remaining operating time of the
receiver (see page 15 and 16)
2 Balance buttons
for right ear
R and left ear L
3 Hearing profile button
for selecting the hearing profiles
(see page 25)
4 Hearing profile LED ,
indicating the activated hearing
profile (see page 25)
5 Audio source button
for selecting the audio source
(see page 21)
6 Charging compartment for ste-
thoset receiver
7 Charging contacts for stethoset
receiver with holding magnets
8 Transmitter status LED
(see page 8)
9 Digital Optical In audio input
(marked pink) for connecting a
digital audio source (optical)
0 5V DC 1A socket (marked yellow)
for connecting the power supply
unit
A Analog 3.5 mm In audio input
(marked blue) for connecting an
analog audio source (3.5 mm jack
socket)
