Sensorex TX105 - Output Menu for Ph

15
5.3.3.1 Standard/slope Calibration Details
Display
Operation
Standard/Slope
Place Sensor
In pH Buffer
#1
Place sensor In pH Buffer #1, and wait 30 seconds
for the sensor to stabilize.
STANDARD/SLOPE
Buffer#1
0mV 7.00PH
Set Standard
00.00
Set the pH value for Buffer #1.
Buffer #1
is Accepted!
No operation is required.
Standard/Slope
Place Sensor
In pH Buffer
#2
Place sensor In pH Buffer #2, and wait 30 seconds
for the sensor to stabilize. The pH values of
Buffer#2 and Buffer #1 shouldn’t be too close.
STANDARD/SLOPE
Buffer#2
177mV 4.01PH
Set Slope
00.00
Set the pH value for Buffer #2.
Buffer #2
is Accepted!
No operation is required.
Standard/Slope
Calibrate
Successfully!
No operation is required.
5.3.4 Output Menu for pH
Display
Description
Menu Item
Next Level Menu
Output 4~20mA>
4~20mA Source>
PH
Sets either pH or temperature as the source
for the 4~20mA current loop output.
Set 4~20mA>
Sets the minimum and maximum
pH/temperature values for the 4~20mA
current loop output.
