Sensorex TX105 - Calibration Menu for ORP; Output Menu for ORP; Options Menu

17
PULSE
RANGE >
00.0014.00 pH
As described in 4.3.2, sets the range.
PULSE RATE>
200 Pulse/min
As described in 4.3.2, sets the pulse rate.
5.3.5 Calibration Menu for ORP
Display
Description
Menu Item
Next Level Menu
STANDARD >
000mv
One Point Cal
0000 mV
Applies a linear calibration to the ORP
measurement.
5.3.6 Output Menu for ORP
Display
Description
Menu Item
Next Level Menu
Output >
4~20mA
Set 4mA Output>
-2000mV
Sets the minimum and maximum ORP
values for the 4 to 20 mA current loop
output.
The valid value range is -2000~+2000 mV.
Set 20mA Output>
2000 mV
OC Output >
OC MODE>
PULSE
See 4.3 Open Collector Output Operation,
selects the OC mode and relative
parameters.
The OC output details for ORP are the same as pH, see section 0.
5.3.7 Options Menu
The Options Menu is the same for both pH and ORP.
Display
Description
CONTRAST >
Level 1
Adjusts the LCD contrast for optimal viewing. A setting of 1
is the lowest contrast, while a setting of 5 is the highest.
