Sensorex TX105 - Electrical Connections; System Power & Loop Connections

8
 Operation: -10 °C to 70 °C (14 °F to 158 °F); 0-95% relative humidity, non-condensing
 Transport/storage: 15°C to 80°C (5°F to 176°F); 0-95% relative humidity, non-condensing
Standards and Approvals
 CE: Certified Compliant to European Community Standards.
4 Electrical Connections
4.1 System Power & Loop Connections
 Standalone application, loop current isn’t used
Power Supply
Transmitter Terminals
24VDC+
+
2
V+/Loop+
24VDC-
-
1
V-/Loop-
 Connection to a PLC with built-in power supply.
PLC Terminals
Transmitter Terminals
24VDC+
+
2
V+/Loop+
24VDC-
-
4-20mA Loop Input
-
1
V-/Loop-
4-20mA Loop Input
+
 Connection to a PLC with separate power supply
Option A
Power Supply
Transmitter Terminals
24VDC+
+
2
V+/Loop+
24VDC-
-
1
V-/Loop-
PLC
4-20mA Loop Input
-
4-20mA Loop Input
+
Option B
PLC
Transmitter Terminals
4-20mA Loop Input
-
2
V+/Loop+
4-20mA Loop Input
+
1
V-/Loop-
Power Supply
24VDC+
+
24VDC-
-
