2.2.2 The vertical timings
2.2.2.1 Binning full scanning
(Settings: address: 10H, value: 1XX10XXX; address: 11H, value: XXX0X000)
1 H = 30.375 µseconds, 31.686 Hz
2.2.2.2 Binning partial scanning
(Settings: address: 10H, value: 1XX11XXX; address: 11H, value: XXX0X000)
1 H = 30.375 µseconds, 31.747 Hz
Video out
1018H
Vertical
blanking
1039H
One vertical (1V)
1018H
21H
Video output active term
2042+2043
2044+2045
10+11
12+13
2
1
H
FVAL
2
1
H
Vertical
blanking
2
1
H
LVAL
DVAL
Video out
1029H
Vertical
blanking
1037H
One vertical (1V)
1029H
8H
Video output active term
2055+2056
2057+2058
3+4
1+2
8
H
FVAL
8
H
Vertical
blanking
8
H
LVAL
DVAL
