4.4 The camera control commands
4.4.1 The camera commands list
Note. 1: The data unit of the each command is 1byte (8bit).
Note. 2: The data can be saved to the EEPROM if “x” in the “Save to EEPROM” column in the list.
Note. 3: The camera is operating with the data of the EEPROM when the power on the camera.
Command Read / Write Save to Function Initial data Data
No. EEPROM range
00 to 0BH Reserved - -
0CH
Read / Write
x
The signals of the power/IO connector at power on (8bit: D[7..0])
0D to 0FH
Reserved
-
-
10H Read / Write x The camera function mode 1 (8bit: D[7..0]) 9
11H Read / Write x The camera function mode 2 (8bit: D[7..0]) 0
12H Read / Write x The camera function mode 3 (8bit: D[7..0]) 0
13H Reserved - -
14H Read / Write x The communication mode (8bit: D[7..0]) 1
15 to1FH Reserved - -
20H Read / Write x The exposure time (H) of the electronic shutter (16bit: D[7..0]) 0 0 to 4095
21H Read / Write x The exposure time (H) of the electronic shutter (16bit: D[15..8])
22H Read / Write x The exposure time (CLK) of the electronic shutter (16bit: D[7..0]) 0 0 to 1919
23H Read / Write x The exposure time (CLK) of the electronic shutter (16bit: D[15..8])
24H Read / Write x The start line of the variable partial scanning (16bit: D[7..0]) 0 0 to 1235
25H Read / Write x The start line of the variable partial scanning (16bit: D[15..8])
26H Read / Write x The effective lines of the variable partial scanning (16bit: D[7..0]) 1236 0 to 1236
27H Read / Write x The effective lines of the variable partial scanning (16bit: D[15..8])
28H Read / Write x The delay time for the trigger (8bit: D[7..0]) 0 0 to 255
29 - 2FH Reserved - -
30H Read / Write x CDS gin (8bit: D[7..0]) 0 0 to 255
31H Read / Write x The digital gain (8bit: D[7..0]) The factory 0 to 255
adjusted value
32H Read / Write x The gain offset (8bit: D[7..0]) The factory 0 to 255
adjusted value
33 to 37H
Reserved
-
-
38H
Read / Write
x
The clamp level (8bit: D[7..0])
4
0 to 31
39 to 67H
Reserved
-
-
68H
Read / Write
x
Digital clamp (8bit: D[7..0])
69H
Reserved
-
-
6AH
Read / Write
x
Manual digital clamp (Left) (16bit: D[7..0])
0
0 to 1023
6BH
Read / Write
x
Manual digital clamp (Left) (16bit: D[15..8])
6CH
Read / Write
x
Manual digital clamp (Right) (16bit: D[7..0])
0
0 to 1023
6DH
Read / Write
x
Manual digital clamp (Right) (16bit: D[15..8])
6E to 77H
Reserved
-
-
78H
Read / Write
x
Test pattern selection (8bit: D[7..0])
0
79H
Read / Write
x
Image effect selection (8bit: D[7..0])
0
7A to 7FH
Reserved
-
-
80H
Read / Write
EEPROM control (8bit: D[7..0])
81 to EFH
Reserved
-
-
F0H
Read / Write
The signals of the power/IO connector (8bit: D[7..0])
F1 to FFH
Reserved
-
-
