SenTech STC-CL500E - 1;2 Partial Scanning

No.11S031-03
9
STC-CL500E/CLC500E
Users guide Rev. 1.3
2.1.2.3 1/2 partial scanning
(Settings: address: 10H, value: 1XX01XXX; address: 11H, value: XXX0X001)
1 H = 30.375 μseconds, 31.686 Hz
2.1.2.4 1/4 partial scanning
(Settings: address: 10H, value: 1XX01XXX; address: 11H, value: XXX0X010)
1 H = 30.375 µseconds, 63.311 Hz
128H
Video out
Vertical blanking
5 2
0 H
One vertical (1V)
128H
3 9 2 H
392H
Video output active term
1015 1016
889 890
FVAL
392H
3 9 2 H
Vertical blanking
LVAL
DVAL
768H
Video out
Vertical blanking
1 0 3 9 H
One vertical (1V)
271H271H
Video output active term
1359 1360
593 594
FVAL
768H271H
Vertical blanking
2 7 1 H
LVAL
DVAL
