21
Motor Head Unit InstallationMotor Head Unit Installation
LISH
E
N
G
When fitting the cover, route the
motor wires and the
interconnecting cable through the
slots in the cover as shown. The
cover is a press-fit, it is not
affixed with screws.
10
Once the motor is attached to the door, the u-bolt may be fastened. With the motor
disengaged, the door needs to be checked for balance, and if necessary,
adjustments made. Additionally if the door is light, it will be necessary to add weight
at the bottom, using a length of angled steel as listed under “Required Equipment”
