LED Status Indicators
26
The LOGLED reports the SD card mount status and logging activity.
LED
LED Behaviour
LOGLED
LED is off when the SD card is not present or not mounted.
LED is on when the SD card is present and mounted. Short blinks
indicate logging activity.
During boot, i.e. during the first seconds after powering the receiver, the state of the LEDs
is not defined.
