Sepura SC20 series Service Guide

Smartcard
If required by your Network Operator, the radio may be fitted with a smartcard to enable access to
the network.
Remove a smartcard
Caution! If a belt clip is fitted to the radio, lift the belt clip before attempting to
remove or fit the battery. Do not attempt to slide the battery into the battery
compartment sideways under the belt clip. This may result in damage to the
radio and the belt clip.
1. Lift the compartment cover using a small screw driver or tweezers. The cover is secured by
two tabs located at the top of the cover, either side of the recess.
2. Remove the card from the slot on the underside of the cover.
3. Close the cover. Using your thumbs, press downward firmly on either side of the cover as
shown to secure each tab.
Caution! Ensure that the compartment cover is secured. Not securing the
cover will affect the radio's IP rating.
Fit a smartcard
1. Lift the compartment cover using a small screw driver or tweezers. The cover is secured by
two tabs located at the top of the cover, either side of the recess.
2. Insert the card into the slot on the underside of the cover as shown, ensuring that the card is
secured between the two tabs.
Level 1 Service Guide 11

Sepura SC20 series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Bands	380-430 MHz
GPS	Integrated GPS, GLONASS
Bluetooth	Bluetooth 4.0
Security	TEA1, TEA2, TEA3
Transmit Power	1W, 3W, 10W
Battery Life	Up to 14 hours (standard battery)
