Sepura SC20 series Service Guide

SC20 Series hand-portable radio
Item Description
1 Antenna.
2 Rugged Accessory Connector (sRAC). Attachment of audio accessories.
3 Audio Ports.
4 Alphanumeric Keypad.
5 Keypad Bezel.
6 Colour Bar.
7 Earpiece and microphone.
8 Navi-knob. A continuously rotating knob for adjusting the volume.
9 Digital Accessory Connector (sDAC). Used for charging the battery when mounted to the
radio, programming the radio and attachment of data accessories.
10 Battery release.
11 Battery.
12 External Antenna Connector.
Level 1 Service Guide 1

Sepura SC20 series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Bands	380-430 MHz
GPS	Integrated GPS, GLONASS
Bluetooth	Bluetooth 4.0
Security	TEA1, TEA2, TEA3
Transmit Power	1W, 3W, 10W
Battery Life	Up to 14 hours (standard battery)
