VE432 STATUS
DPG
0311385 Issue : April 1999
8-1
VE432 STATUS
DPG
no hiline sync The DPG started but failed to find the requested 50 Hz
synchronization.
custom error No sweep (same as DSD status 22)
timeout error No sweep, DPG hardware malfunction.
DSD
1 Normal, Raw mode.
12 Normal, Filtered mode.
19 Normal, Timing error (indicative of discrepancy between
DPG and DSD clocks).
2 Sweep aborted by DSD. Hardware malfunction (DVC).
10 User abort.
13 Discrepancy in DPG and DSD acquisition tables. Use the
SET DSD function to correct the inconsistent table.
14 Lift not ready.
22 Custom error (Custom sweep does not exist on PCMCIA
card) or can’t read from PCMCIA card.
98 No T0 data received (sweep failed to start, or radio
malfunction).
99 No T0 data received or no status report (sweep failed to
start, or DPG failed to receive consistent DSD status).
26 The Slave acquisition unit did not start any acquisition.
The Status file generated by the DPG can be exported to a spreadsheet application
as follows:
- Open the LOG main window. Click LOG VIEW. From the option button in
the LOG View dialog box, select DPG Normal Acq status. From the list
box, select the desired file. Click Apply.
- From the Device button in the LOG main window, select Internal Disk.
Enter a name for the file to be exported (e. g. fileName). Click Apply.
Indicative of a
sweep with no
status value
