CONNECTING A DPG
DPG STANDARD CONNECTIONS
0311385 Issue : April 1999
2-2
DPG STANDARD CONNECTIONS
GROUND
wing nut
COM 1
(to palmtop computer)
ANALOG PILOTS
RETURN SWEEP
RETURN PILOT
TB
PILOT 2
PILOT 1
ETHERNET
RECORDER
(to recording system)
COM 2
Radio
Fuse
AC
power
HI. LINE
